英管螺纹O型圈密封柱端
| PART NO. | THREAD | TUBE | DIMENSIONS | WEIGHT | WORKING PRESSURE | SERIES | |||||||
| T1 | T2 | D1 | D2 | L1 | L2 | L3 | L4 | 1 | S2 | g/pc | (bar) | ||
| 1CG-12-02 1CG-12-04 1CG-12-06 1CG-12-08 1CG-14-02 1CG-14-04 1CG-14-06 1CG-14-08 10G-16-02 10G-16-04 1CG-16-06 1CG-16-08 1CG-18-02 10G-18-04 10G=18-06 10G-18-08 1CG-18-12 1CG-22-06 1CG-22-08 1CG-22-12 1CG-26-06 1CG-26-08 1CG-26=12 10G-30-08 1CG-30-12 10G-30-16 1CG-36-08 1CG-36-12 1CG-36-16 1CG-36-20 1CG-45-12 1CG-45-16 1CG-45-20 1CG-45-24 1CG-52-16 1CG-52-20 |
M12 x1.5 M12 x1.5 M12 x1.5 M12 x1.5 M14 x1.5 M14x1.5 M14 x1.5 M14x1.5 M16x1.5 M16x1.5 M16x1.5 M16x1.5 M18x1.5 M18x1.5 M18x1.5 M18x1.5 M18x1.5 M22x1.5 M22x1.5 M2x1.5 M26x1.5 M26x1.5 M26x1.5 M30x2 M30x2 M30x2 M36x2 M36x2 M36x2 M36x2 M45x2 M45x2 M45x2 M45x2 M52x2 M52x2 |
G1/828 G1/4″x19 G3/8″x19 G1/2″x14 G1/8″x28 G1/4″x19 G3/8″x 19 G1/2″x14 G1/8″x28 G1/4 “x19 G3/8″x19 G1/2″x14 G1/8″x28 G1/4″x19 G3/8″x19 G1/2″x14 G3/4″x14 G3/8″x19 G1/2″x14 G3/4″x14 G3/8″x19 G1/2″x14 G3/4″x14 G1/2″x14 G3/4″x14 G1″x11 G1/2″x14 G3/4″x14 G1″x11 G1.1/4″x11 G3/4″x14 G1″x11 G1.1/4″x11 G1.1/2″x11 G1″x11 G1.1/4″x11 |
6 6 6 6 8 8 8 8 10 10 10 10 12 12 12 12 12 15 15 15 18 18 18 22 22 22 28 28 28 28 35 35 35 35 42 42 |
14 18 22 26 14 18 22 26 14 18 22 26 14 18 22 26 32 22 26 32 22 26 32 26 32 39 26 32 39 50 32 39 50 55 39 50 |
23.5 29 30.5 33 23.5 29 30.5 33 25.5 30 31.5 34 26.5 31 31.5 34 37 32.5 35 38 33.5 36 38 38 40 43 39 41 43 46 44 46 48 52 48 50 |
8.5 10 11.5 12 8.5 10 11.5 12 10.5 11 12.5 13 11.5 12 12.5 13 14 13.5 14 15 14 14.5 14.5 16.5 16.5 17.5 17.5 17.5 17.5 18.3 17.5 17.5 17.5 19.5 19 19 |
8 12 12 14 8 12 12 14 8 12 12 14 8 12 12 14 16 12 14 16 12 14 16 14 16 18 14 16 18 20 16 18 20 22 18 20 |
23 25 26 27 23 25 26 27 25 26 27 28 26 27 27 28 29 29 29 30 29.5 31 30 33 33 33.5 34 34 34 35 39 39 39 41 42 42 |
14 19 22 27 14 19 22 27 17 19 22 27 19 19 22 27 32 24 27 32 27 27 32 32 32 41 41 41 41 41 46 46 46 55 55 55 |
14 14 14 14 17 17 17 17 19 19 19 19 22 22 22 22 22 27 27 27 32 32 32 36 36 36 41 41 41 41 50 50 50 50 60 60 |
14 60 45 60 16 26 44 74 21 31 44 72 27 32 43 67 120 56 72 118 69 72 112 91 103 184 141 156 168 314 202 234 276 355 327 336 |
315 315 315 315 315 315 315 315 315 315 315 315 315 315 315 315 315 250 250 250 250 250 250 160 160 160 160 160 160 160 160 160 160 160 160 160 |
L L L L L L L L L L L L L L L L L L L L L L L L L L L L L L L L L L L L |
注:如需带卡套和卡套螺母整套订货，则请在代号后面加 “RN” 如 1CG-52-20/RN,需搭配挡圈请在代号后加“DQ” 例如 1CG-52-20DQ
